Specification
|
|
Input signal
|
2 channel voltage from accelerometer
|
|
Amplitude ranges & frequency response of overall measurement
|
Displacement
|
0.001 – 5 mm peak-peak, 10 - 500 Hz
|
|
Velocity
|
0.1 - 200 mm/s true RMS, 10 - 1000 Hz
|
|
Acceleration
|
0.1 - 250 m/s² peak, 10 - 10 kHz
|
|
Acceleration envelope
|
0.1 - 20 m/s² true RMS, 5 Hz -2 kHz from 15-40 kHz
|
|
Voltage
|
0.1 - 10 V peak-peak, 0.5 Hz - 10 kHz
|
|
Amplitude spectrum analysis
|
100 and 400 lines, Hanning window
|
|
Frequency span of spectrum analysis
|
100Hz, 200Hz, 500Hz, 1 kHz, 2 kHz, 5 kHz, 10 kHz (1 channel only)
|
|
Data storage
|
62 1024-point time waveforms and 240 data sets
|
|
Notepad
|
10 condition codes for visual inspection
|
|
Output
|
RS232C
|
|
Power
|
Ni-MH rechargeable battery up to 8 hours continuous operation, low battery voltage warning
|
|
Operating environment
|
0～50 °C, up to 90% humidity but non-condensing
|
|
Rotating speed measurement range
|
180-24000 r/min (with laser-aimed tacho sensor)
|
|
Dynamic range
|
60 dB with 48 dB gain range
|
|
Gain adjustment
|
Automatic or manual- adjustment selectable
|
|
Anti-aliasing filter
|
8th order elliptic low-pass
|
|
Dimensions
|
21×13×4 cm
|
|
Weight
|
1.2 kg
|
